SPF450B Hydraulic Pile Breaker Specification
| Model |
SPF450B |
| Range of Pile diameter (mm) |
350-450 |
| Maximum Drill rod pressure |
790kN |
| Maximum stroke of hydraulic cylinder |
205mm |
| Maximum pressure of hydraulic cylinder |
31.5MPa |
| Maximum flow of single cylinder |
25L/min |
| Cut the number of pile/8h |
120 |
| Height for cutting pile each time |
≤300mm |
| Supporting the digging machine Tonnage(excavator) |
≥20t |
| Work status dimensions |
1855X1855X1500mm |
| Total pile breaker weight |
1.3t |
Key Credentials & Qualifications
A
Obtained more than 20 patents and exported to more than 60 countries.
B
A professional R&D team with 10 years of industry experience.
C
Passed ISO9001 quality management system certification, obtained CE certification.
D
Engineer overseas service. Ensure the quality of the machine and good after-sales service.
Product Advantages & Features
- High Efficiency: Hydraulic pile breaker provides high efficiency and low noise pile cutting.
- Modularization Design: Cutting pile heads of different diameters can be realized by combining different numbers of modules.
- Cost-Effective: Delivers high productivity with exceptionally low operating cost.
- Simple Operation: The operation of pile breaking is simple, safe, and requires no professional skills.
- Universal Connection: Pile breaking machine can be connected with a variety of construction machinery to achieve product universality and economy. Can be hung on excavators, cranes, telescopic booms, and other construction machinery.
- Conical Top Design: The conical top design avoids the accumulation of soil in the guide flange, preventing steel stuck, deviation, and easy fracture.
- Earthquake Resistance: The steel drill rotates at any time to effectively prevent vibration in the high-pressure cylinder, preventing connection fractures.
- High Durability: The high-life design ensures long-term operational benefits to customers.
Frequently Asked Questions
What pile diameters can the SPF450B Hydraulic Pile Breaker cut?
The SPF450B is designed to cut pile diameters ranging from 350mm to 450mm. Its modular design allows users to combine different numbers of modules to adapt to varying pile head diameters.
What type of excavator tonnage is required to support this equipment?
The SPF450B requires a supporting digging machine (excavator) with a tonnage rating of 20 tons or greater (≥20t).
How many piles can this machine cut in an 8-hour shift?
The SPF450B is highly efficient and can cut up to 120 piles within an 8-hour shift. The cutting height for each operation is ≤300mm.
Can the pile breaker be connected to other machinery besides excavators?
Yes, it is designed for great universality and economy. It can be hung on excavators, cranes, telescopic booms, and various other types of construction machinery.
How does the design prevent steel stuck and cylinder damage?
The conical top design prevents soil from accumulating in the guide flange, eliminating steel stuck, deviation, and easy fracture. Additionally, the steel drill rotates continuously to prevent vibration in the high-pressure cylinder, preventing connection fractures.
Is professional training required to operate this pile breaker?
No, the operation of this hydraulic pile breaker is straightforward and highly secure. No specialized skills or professional training are required to operate it safely.
