Based on different stratum, we can adjust torque and rotary speed of drilling rig to increase drilling rig’s adaptability. At the same time, we can adjust torque and rotary speed according to client's request.
With the crawler, it has the following technical features: fast mobility, accurate location, time saving, good reliability and stability. It can also reduce labor intensity and increase efficiency after equipping the clamping and breaking device.
Our R&D department also develops relative drilling tools to meet the following construction technology:
| Specifications | SD-150 |
| Hole diameter (mm) | ф150 ~ ф250 |
| Hole depth (m) | 130 ~ 170 |
| Rod diameter (mm) | ф73, ф89, ф102, ф114, ф133, ф146, ф168 |
| Hole angle (°) | 0 - 90 |
| Output speed of rotary head (max) (r/min) | 170 |
| Output torque of rotary head (max) (N.m) | 7500 |
| Stroke of rotary head (mm) | 3400 |
| Stroke of slide flame (mm) | 900 |
| Lifting force of rotary head (kN) | 70 |
| Lifting speed of rotary head (m/min) | 0 ~ 5 / 7 / 23 / 30 |
| Feeding force of rotary head (kN) | 36 |
| Feeding speed of rotary head (m/min) | 0 ~ 10 / 14 / 46 / 59 |
| Input power (Electromotor) (kW) | 55 + 22 |
| Dimension (L*W*H) (mm) | 5400 * 2100 * 2000 |
| Weight (kg) | 6000 |
