Close-circuit system is adopted for rotation and push & pull both, which increases work efficiency by 15%-20%, and totally saves 15%- 20% energy compared with traditional system.
Rotation and Thrust motor all use Poclain motors, realizing more stable and reliable control and quicker response.
It is equipped with Cummins engine specialized in engineering machinery with strong power.
Wireless walking system ensures the safety for walk and transfer.
Newly developed reversible manipulator is convenient for loading and unloading drill rod, which can greatly reduce the workers labor intensity and improve work efficiency.
Applicable for φ 89x3000mm drill rod, the machine fits moderate field area, meeting the requirement for high efficiency construction in small downtown district.
Main hydraulic components are from the international first-class hydraulic components manufacturer, which can greatly improve the reliability of the product performance and safety.
Electric design is reasonable with low failure rate, which is easy to maintain.
Rack & pinion model is adopted for push & pull, which ensures high efficiency, stable work and convenient maintenance.
Steel track with rubber plate can be loaded heavily and walk on all kinds of roads.
| Parameter Specifications | |
|---|---|
| Engine Power | 194/2200KW |
| Max Thrust force | 450KN |
| Max Pullback force | 450KN |
| Max Torque | 25000N.M |
| Max Rotary speed | 138rpm |
| Max Moving speed of power head | 42m/min |
| Max Mud pump flow | 450L/min |
| Max Mud pressure | 10±0.5Mpa |
| Size(L*W*H) | 7800x2240x2260mm |
| Weight | 13T |
| Diameter of drilling rod | ф 89mm |
| Length of drilling rod | 3m |
| Max diameter of pullback pipe | ф 1400mm (Soil Depended) |
| Max construction length | 700m (Soil Depended) |
| Incidence Angle | 11~20° |
| Climbing Angle | 14° |
The closed-circuit hydraulic system is utilized for both rotation and push/pull functions. This design increases working efficiency by 15% to 20% and reduces energy consumption by 15% to 20% compared to traditional open systems.
The equipment is powered by a high-performance Cummins engine specifically designed for engineering machinery. For rotation and thrust, it utilizes premium Poclain motors to ensure stable, reliable control and quick operational response.
The machine is designed to work with φ 89x3000mm drill rods. It is optimally sized for moderate field areas and high-efficiency construction in tight downtown districts.
Yes, it features a wireless walking system to ensure safety during transport. Additionally, the heavy-duty steel track is equipped with rubber plates, allowing the machine to load heavily and travel across all types of roads without damaging the surface.
The machine delivers a maximum thrust force of 450KN and a maximum pullback force of 450KN, ensuring strong performance for challenging drilling projects.
It features a newly developed reversible manipulator designed for convenient loading and unloading of drill rods. This mechanism significantly reduces the operator's labor intensity while increasing overall job-site efficiency.
