Advanced Rotation Head: Uses advanced rotation technology driven by dual hydraulic motors with mechanical speed changing. Delivers a wide speed range and high torque at low speeds to accommodate various geological conditions.

Deep Drilling Capability: Reaches a maximum spindle speed of 1175rpm with a torque of 432Nm, optimized specifically for deep exploration requirements.

High-Efficiency Feeding: The feeding and lifting systems utilize a single hydraulic cylinder driving the chain, allowing for long feeding distances suitable for extended core drilling processes.

Operator Convenience: The hydraulic driving head can move away from the borehole. Combined with clamp, unscrew, and rod assistant systems, it greatly simplifies operations.

Reduced Down-Time: High lifting speed reduces auxiliary operations, facilitating rapid hole washing and increasing overall productivity.

Mast Stability: The V-style orbit on the mast provides strong rigidity between the top hydraulic head and the mast, ensuring stable rotation even at high speeds.

Premium Winch Systems: Features a reliable American BRADEN main winch and a fast secondary wireline winch reaching empty-drum speeds up to 205m/min.

Lower Work Intensity: Standard clamp and unscrew mechanisms streamline rod connections and disconnections, protecting operators from excessive strain.

Precise Monitoring: Equipped with real-time spindle speedometers and drilling depth gauges for precise, data-driven drilling operations.

Balanced Down-Hole Pressure: Back-pressure balance system helps monitor and adjust drilling pressure accurately, extending the overall lifecycle of drilling bits.

Concentrated Control Panel: Features a reliable hydraulic control system with valves and operation handles centralized on a single panel for quick handling of drilling incidents.

Safe Crawler Mobility: Equipped with a crawler base and electronic handle controllers. It also supports external control connections to ensure safe relocation.
