| Item |
Unit |
YTQH350B |
| Compaction capacity |
t.m |
350(700) |
| Hammer weight permit |
t.m |
17.5 |
| Wheel tread |
mm |
5090 |
| Chassis width |
mm |
3360(4520) |
| Track width |
mm |
760 |
| Boom length |
mm |
19-25(28) |
| Working angle |
° |
60-77 |
| Max.lift height |
mm |
25.7 |
| Working radius |
mm |
6.3-14.5 |
| Max. pull force |
t.m |
10-14 |
| Lift speed |
m/min |
0-110 |
| Slewing speed |
r/min |
0-1.8 |
| Travel speed |
km/h |
0-1.4 |
| Grade ability |
|
40% |
| Engine power |
kw |
194 |
| Engine rated revolution |
r/min |
1900 |
| Total weight |
t.m |
58 |
| Counter weight |
t.m |
18.8 |
| Main body weight |
t.m |
32 |
| Dimension(LxWxH) |
mm |
7025x3360x3200 |
| Ground pressure ratio |
M.pa |
0.073 |
| Rated pull force |
t.m |
7.5 |
| Lift rope diameter |
mm |
26 |
Key Advantages & Features
-
✓
Wide application range of dynamic compaction construction
-
✓
Excellent power performance
-
✓
High strength, reliability and stability chassis
-
✓
High boom strength
-
✓
Big single rope line pull for lifting winch
-
✓
Easy and flexible control
-
✓
Long-time and high-power operation
-
✓
High safety
-
✓
Comfortable operation
-
✓
Easy transportation
Frequently Asked Questions
Q: What is the dynamic compaction capacity of the YTQH350B?
The YTQH350B has a rated dynamic compaction capacity of 350 t.m, with a maximum capability reaching up to 700 t.m.
Q: What are the specifications of the engine installed in this machine?
It is equipped with a high-performance engine that delivers 194 kW of power at a rated revolution of 1900 r/min, ensuring efficient, long-term operation under heavy loads.
Q: What is the boom configuration for the YTQH350B?
The standard boom length ranges between 19 and 25 meters, extendable up to 28 meters, operating within a working angle range of 60° to 77°.
Q: How is the ground stability managed during operation?
Stability is maximized through a high-strength chassis configuration featuring a 5090 mm wheel tread, 760 mm track width, and a low ground pressure ratio of 0.073 M.pa to ensure safe operations on varied terrains.
Q: What are the weight distributions and transport dimensions?
The main body weight is 32 tons, the counterweight is 18.8 tons, and the total weight is 58 tons. For transportation, the overall dimensions are 7025 mm (L) x 3360 mm (W) x 3200 mm (H).
