Discount Coral Type Grab Pricelist, Exporter

Send Inquiry

Product Description

Model	Coral type grab-SPC470	Coral type grab-SPC500
Range of Pile diameter(mm)	Φ650-Φ1650	Φ1500-Φ2400
Cut the number of pile/9h	30-50	30-50
Height for cut pile each time	≤300mm	≤300mm
Supporting the digging machine Tonnage (excavator)	≥30t	≥46t
Work status dimensions	Φ2800X2600	Φ3200X2600
Total pile breaker weight	5t	6t
Maximum Drill rod pressure	690kN	790kN
Maximum stroke of hydraulic cylinder	470mm	500mm
Maximum pressure hydraulic cylinder	34.3MPa	35MPa

Frequently Asked Questions

What pile diameters can the Coral Type Grab handle?

The SPC470 model supports a pile diameter range of Φ650mm to Φ1650mm, while the SPC500 model handles larger diameters from Φ1500mm to Φ2400mm.

What is the cutting capacity of the equipment per shift?

Both the SPC470 and SPC500 models are designed for high efficiency, capable of cutting between 30 and 50 piles in a standard 9-hour working shift.

What size excavator is required to support these grabs?

The SPC470 requires a supporting excavator tonnage of ≥30t, while the larger SPC500 model requires a minimum excavator tonnage of ≥46t.

What is the maximum height of pile that can be cut in a single operation?

For both models, the maximum height of concrete pile that can be cut during each individual operation is ≤300mm.

What are the stroke and pressure limits of the hydraulic cylinder?

The SPC470 features a maximum hydraulic stroke of 470mm and a pressure of 34.3MPa. The SPC500 features a stroke of 500mm with a maximum pressure of 35MPa.
