| Parameter | Specification Details |
|---|---|
| Engine Power | 2*242/2200KW |
| Max Thrust force | 1800/2400KN |
| Max Pullback force | 1800/2400KN |
| Max Torque | 78000N.M |
| Max Rotary speed | 100rpm |
| Max Moving speed of power head | 35m/min |
| Max Mud pump flow | 1000L/min |
| Max Mud pressure | 10±0.5Mpa |
| Size(L*W*H) | 12900×3000×3100mm |
| Weight | 33T |
| Diameter of drilling rod | Φ127mm |
| Length of drilling rod | 6m |
| Max diameter of pullback pipe | Φ1500mm Soil Depended |
| Max construction length | 1500m Soil Depended |
| Incidence Angle | 11~22° |
| Climbing Angle | 15° |
The rotation and thrust features the USA Sauer closed-circuit system. The rotation motor is an originally imported French Poclain brand, while the push & pull motor is from Germany Rexroth, saving about 20% energy compared to traditional systems.
It is equipped with two Cummins engines specialized for engineering machinery, providing a strong power output of 2*242/2200KW.
The driving head reserves reinforced power allowing the push & pull force to be increased up to 2400KN, ensuring safe big diameter construction operations.
The main girder adopts a four-bar linkage luffing structure, which highly increases the entry angle range (11~22°). This design ensures that the rig tracks do not lift off the ground even at large angles, greatly enhancing safety.
Yes, it is designed with a heavy-load steel track with rubber plates, enabling the machine to walk safely on all kinds of road surfaces.
It uses a Φ127mm diameter and 6m long drilling rod (or Φ114×6000mm depending on config) and is capable of handling a maximum pullback pipe diameter of Φ1500mm and construction length up to 1500m (soil dependent).
