CE Certification SH5D Deep Soil Mixing Drilling Rigs Factories, Exporter

Send Inquiry

Product Description

Key Performance Highlights

Main Motor Power

75KW

Drilling Force

460KN

Max Pile Depth

≤28M

Max Pile Diameter

≤1200mm

Technical Specifications Table

Parameter	Specification details
Main motor	75KW
Diameter	Ø1200mm
Drilling motor	18.5KW
Oil pump motor	18.5KW
Drilling force	460KN
Drilling speed	0.05-2.2m/min
Rotating speed (Forward)	Forward 5-96RPM
Rotating speed (Reverse)	Reverse 5-90RPM
Total Weight	25000KG
Pile depth	≤28M
Drill rod specifications	180x180x16mm
Pile diameter	≤1200mm
Core pile section size	500-1200mm
Chain Size	36A
Mast structure height (M)	Type II-30M
Hydraulic walking (Longitudinal step)	1.8M
Hydraulic walking (Horizontal step)	0.6M
Base frame size	8200*2300mm

Frequently Asked Questions

What is the total motor configuration of this equipment?

The equipment features a main motor of 75KW, a drilling motor of 18.5KW, and an oil pump motor of 18.5KW to ensure efficient power distribution.

What are the maximum pile depth and diameter capability limits?

This machinery supports a pile depth of ≤28 meters and can accommodate a maximum pile diameter of ≤1200mm, with a core pile section size ranging from 500 to 1200mm.

What are the drilling speed and rotation speed specifications?

The equipment operates at a drilling speed of 0.05-2.2m/min. The rotating speed ranges from 5 to 96 RPM in forward direction and 5 to 90 RPM in reverse.

What are the dimensions and total weight of the machine?

The total weight of the equipment is 25000KG. It features a base frame size of 8200*2300mm and a Type II mast structure height of 30 meters.

How does the hydraulic walking system perform?

The integrated hydraulic walking system supports a longitudinal step length of 1.8 meters and a horizontal step length of 0.6 meters.

What are the drill rod and chain specifications for this machinery?

This equipment utilizes a drill rod specification of 180x180x16mm and a chain size of 36A.
